Product Detail

Model No.: 2V Series

Production Capacity: 1000 pcs per week

Delivery Date: 2-4 weeks

Standard or Nonstandard: Standard

Structure: Diaphragm

Temperature of Media: Medium Temperature

Brand Name: XCPC

Operation Fluid Viscosity: 20 CST (Below)

Voltage Range: 10%

Power Consumption: AC:4.5VA DC:3W

Means of Transport: Ocean,Air;courier

Packing: international standard,wood...

Power: Solenoid

Pressure: Medium Pressure

Material: Alloy

Media: Others

Medium Motion: Air,Water,Oil

Operating Temperature Range: -10~+80

Protect Class: IP65

Insulation: F Class

1.Voltage Range: 10%
2.Protect Class: IP65
3.Power Consumption: AC:4.5VA DC:3W
4.Insulation: F Class

product name : 2V Series 2/2 Way Solenoid Valve

Standard or Nonstandard: Standard
Structure: two way two position
Pressure: Medium Pressure
Power: Pneumatic
Material: Brass
Temperature of Media: Medium Temperature

Ordering Code

Specification

Model	2V010-M4	2V025-06	2V025-08	2V130-10	2V130-15	2V250-20	2V250-25
Medium Motion	Air,Water,Oil
Pattern	Direct Drive Type			Guide Type
Type	Normal Close Type
Aperture of Flow Rate(mm)	1.0	2.5		13		25
CV Value	0.10	0.23		6.2		23
Port Size	M4X0.7	G1/8"	G1/4"	G3/8"	G1/2"	G3/4"	G1"
Operation Fluid Viscosity	20 CST (Below)
Working-pressure	Air,Water,Oil? 0.05~0.7MPa
Max. Pressure Resistance	1.2	1.6		1.0
Operating Temperature Range	-10~+80
Voltage Range	10%
Protect Class	IP65
Power Consumption	AC:4.5VA?? ?DC:3W
Insulation	F Class
Material of Body	Aluminum or Brass (Nickel coated)			Brass
Material of Oil Seal	NBR or VITON			NBR or VITON
Shortest Excitation Time	0.05 Second
